DW5422 Foam Ball Rebound Tester is used for determining the resilience by ball rebound of flexible cellular polymeric materials. A steel ball with certain diameter and mass is dropped on a foam specimen from a specified height and the height of rebound is measured. The ratio of the ball rebound height to the drop height in percent can be calculated and displayed automatically.
DW5422
FYI
Black+Sliver
1PCS
China
DW5422 Foam Ball Rebound Tester Rebound Resilience Tester is used for determining the resilience by ball rebound of flexible cellular polymeric materials. A steel ball with certain diameter and mass is dropped on a foam specimen from a specified height and the height of rebound is measured. The ratio of the ball rebound height to the drop height in percent can be calculated and displayed automatically.
ISO 8307: 2007 | ASTM D3574 -17 | GB/T 6670-2008 |
Note: Rebound Resilience Tester can conform to but not limit to the standards above, for more standards conformance, please contact us.
Inside diameter of vertical transparent tube | ISO: Ф30~65mm; ASTM: Ф(40±4)mm |
Steel ball diameter | ISO: (16±0.5)mm; ASTM: (16.0±0.2)mm |
Steel ball mass | ISO: (16.8±1.5)g; ASTM: (16.3±0.2)g |
Height of drop | ISO&ASTM: (500±0.5)mm GB: (500±0.5)mm and (460±0.5)mm |
Control mode | PLC + Touch screen |
Power supply | AC220V, 50Hz |
Dimensions | 650×330×920mm (L×W×H) |
Weight | 45kg |
