Introduction:
Textile machinery has played a significant role in revolutionizing the
textile industry. Among the various types of machinery, rapier loom, warping machine, and sizing machine have greatly contributed to enhancing productivity and efficiency. In this article, we will delve into these three important machines, exploring their functions, benefits, and impact on the textile production process.
Rapier loom are an advanced type of weaving machine that have revolutionized the process of fabric production. Rapier loom machine is comprised of control part(computerized control platform) and mechanical part (loom). Control part is controlled by PLC and working frequency controller, key parts of mechanical part including pneumatic element, electric element and stepping motor etc. are imported with original package, thus ensuring stability and reliability of equipment operation. Gaiting length, shed shape and size of sample loom are proportionally contracted and enlarged with new type rapier loom to ensure that warp tension and extensibility of sample loom are in conformity with rapier loom, moreover, same adjustment mode of looming technical parameters as that of new type rapier loom is used in this sample loom, so quality of sample is controlled more precisely
These looms employ a rapier system to insert the weft yarn through the shed created by the warp threads. Unlike conventional shuttle looms, rapier looms eliminate the need for shuttles, resulting in higher weaving speeds and reduced downtime. This technology allows for the production of complex patterns and designs with precision and consistency.
Compared with traditional semi-automatic sampler, this sampler can improve sample efficiency, besides, it fully solves difference between sample and bulk order products and sample difficulty of fabric including multiple heald frame and double circulation etc. in the past.
Warping machines are used to prepare the warp yarns for the weaving process.
Our GA193-400 or GA193-600 serials sectional warping machine is composed of control part and mechanical part. Control part is controlled by inverter. Mechanical part is composed of drum drive, servo motor move ,brake device , automatic beam device, etc. The reasonable combination of above two parts enables the single yarn winder on the drum according to design.
Drum drive: Drum drive is made of lightweight aluminum, the structure is simple and light, and it is driven by motor through connect belt.
Servo move: Use of profiles and linear guide, the yarn arrangement precise is controlled by servo motor.
Brake device: The brake is effect through the steel belt controlled air cylinder
Automatic beam device: The beam is driven by motor, adjustable width, reliable and flexible and lightweight.
They facilitate the winding of parallel yarns onto a beam, ensuring uniform tension and alignment. By creating a warp beam with evenly wound yarns, warping machines contribute to high-quality fabric production. Small Sample Warping Machine is used for automatic warping of production sample, weaving sample and small batch fabrics for lab.
These machines also enable continuous warp beam production, reducing the downtime required for warp beam changes. Additionally, automatic tension control systems ensure consistent tension throughout the entire length of the warp beam.
Sizing machine are employed in the textile industry to apply a protective coating, known as size, on the warp yarns before weaving.
This Yarn Single end Sizing Machine is composed of control part and mechanical part. Control the sizing speed with singe spindle transducer and measure the length and speed with the electronic meter; ② Control the temperature in dryer stove with temperature thermostat, temperature controller, pneumatic steam stop valve (heated by steam),and solid-state relay (heated by electricity) in a closed loop.
Sizing system：The yarn unwinding down from the reel will go into the sizing trough through the yarn-guiding ceramic foot, tension adjuster, yarn-guiding hook and yarn-guiding ceramic roller, and then it goes into the dryer stove.
Drying system
Operating principle (below drawing): The hot air circulation blower will blow the air to the heater (either by steaming or electrical-heating) and then to the dryer stove. The hot humid air produced in the dryer stove will go into the hot air circulation blower through the hot air return pipe, with the humid air being discharged. In this way, the hot air circulation is completed to reach the purpose of yarn drying.
Single Yarn Sizing Machine is suitable for yarn sizing of cotton, flax, silk, wool, synthetic filament, etcThe size acts as a lubricant, preventing yarn breakage during the weaving process. Sizing machines help in achieving better weaving efficiency, as they reduce friction between the yarns and the weaving elements. They also enhance the appearance and durability of the fabric by ensuring better yarn cohesion.
Benefits which get it from our sample weaving system
1. The use of rapier loom, warping machine, and sizing machine has revolutionized the textile industry in several ways. Firstly, these machines have significantly increased production speed and efficiency, enabling manufacturers to meet growing market demands. The elimination of shuttle-related downtime in rapier looms and continuous warp beam production in warping machines have greatly reduced idle time, resulting in higher productivity.
2. Secondly, the precision and accuracy offered by these machines have opened up new possibilities in fabric design and customization. Rapier looms allow for intricate patterns and designs with excellent repeatability, while warping machines ensure uniformity in yarn tension and alignment, leading to superior fabric quality. Sizing machines contribute to increased fabric durability by preventing yarn breakage during weaving.
3. Furthermore, these machines have also improved worker safety and comfort. The automated features of rapier weaving machine, sectional warping machine, and textile sizing machine have reduced manual labor requirements and minimized the risks associated with repetitive tasks. Workers can focus on machine monitoring and maintenance, ensuring a safer working environment.
Conclusion:
Rapier loom, warping machine, and sizing machine have revolutionized the textile industry, improving productivity, efficiency, and fabric quality. These advanced machines have replaced traditional methods, providing precise and consistent results. As technology continues to advance, it is expected that further innovations in textile machinery will continue to shape the industry, meeting the evolving demands of the global market.
