Views: 7 Author: Site Editor Publish Time: 2025-08-21 Origin: Site
TECHNICAL SPECIFICATIONS
(LABORATORY EQUIPMENT)
PURPOSE
The main purpose of these specifications is the purchase of equipment for textile, leather and footwear analysis
laboratories.The equipment requested must meet the technical specifications. Any tender that does not comply with the articles of these technical specifications and with the characteristics indicated in the technical data sheet will be rejected.
TICLE 1: TECHNICAL EVALUATION
The technical offer of each tenderer must contain :
1) These technical specifications and the technical specifications sheet (Administration Issue) for the equipment requested signed and sealed on each page.
2) The technical document for each piece of equipment proposed.
3)he certificate of conformity of each device to the standards in force.
4) A written commitment to the training and technical assistance of two technicians (§5) for the maintenance, servicing and repair of the equipment requested.
ARTICLE 3: ACCEPTANCE
The inspection of the equipment at provisional acceptance is carried out as follows:
1) Visual inspection of the equipment for any breaks, scratches and anomalies that may have occurred during transport.
2) Checking the accessories and documents that must be supplied with the equipment.
3) Verification of equipment conformity certificates and warranty certificates supplied by the manufacturer.
4) Equipment must be delivered in its original packaging.
3.2- Final acceptance:
Final acceptance of the laboratory equipment will only take place after installation, start-up and calibration of each piece of equipment. The final acceptance report must be attached to and refer to the installation and start-up report.
I. General description ：Tensile strength tester YG026PC
This machine measures the fractional resistance force required to break the threads of a leather fabric. It can be connected to a PC or equipped with a computer with an integrated touch screen.
- Clamps for tensile testing of textiles (ISO13934-1; ISO 13934-2)
- Clamps for textile tear test (ISOI3937-2).
- Grips for textile seam slip test (ISO 13936-2).
Make /Model /Reference | YG026PC |
Country of origin | China |
Application | Determine the mechanical property of light woven fabric, light knitted fabric |
Application | Non-woven fabric, including tensile, tearing, seam slippage,elastic recovery, etc. |
Measurement units | N, cN, lbf, kgf, gf,mm. |
Dad quoted force cell | 5KN |
Accuracy | ±0.5%FS |
Vertical space | 1530mm |
Maximum crossbar travel | 950mm(without clamp) |
Column spacing | 370mm |
Frame rigidity | 50 KN/mm |
Speed range | 1-1,000mm/min |
Maximum force at full speed | 5KN |
2. General description ：Semi-automatic waterproofing meter YG812S
This is a device for testing the resistance of a fabric to penetration by a column of water. It must comply
with ISO 811 and ISO 1420 standards.
Technical characteristics
Make /Model /Reference | YG812 Series |
Country of origin | China |
Destination | Applied to determine the resistance of fabrics to water penetration. |
Test pressure | 0 ~ 200kPa |
Accuracy | 0.01kPa |
Test gradient | 1kPa/min, 6kPa/min, 10kPa/min, 100kPa/min |
Drop detection | automatic |
Measurement unit | kPa, mmHg, mbar |
Display | Touch screen display |
Power supply | AC220V, 50Hz |
Warranty | 1 year |
3. General description ：Electronic Part Thickness Gauge DW1141D
The Electronic Piece Thickness Gauge is a device for measuring the thickness of leather and other textile products.
It must comply with ISO 2589 and ISO 5084 standards.
Make /Model/Reference | DW1141D |
Country of origin | China |
Destination | Determine the thickness of various geosynthetics, woven, nonwoven , knitted fabrics and lether under a certain pressure. |
Accuracy | 0.01mm |
Measurement range | 0.001~20mm |
Display | Digital LED |
Warranty | 1 year |
4. General description : BENNEWART”FLEXOMETER” DW9610A
This equipment is used to assess the cracking deterioration of grooved surfaces. This test applies to the outer part of
shoe soles. This equipment must meet the requirements of standards ISO 5423 and EN ISO 20344.
Technical specifications :
Make /Model /Reference | DW9610A |
Country of origin | China |
Number of stations | 3 |
Bending speed | 0~150cycles/min, adjustable |
Bending angle | 90°±1° |
Accessories and documents to be supplied | - Tool for incising the soles(Optional; -Supplied with manufacturer's certificate; - User manual (English) - Detailed spare parts and accessories |
Warranty | 1 year |
5. General description : ROTARY SOLEPLATE SANDER DW5440
This is a machine which measures the resistance to use by contact/friction with the ground of materials used to
manufacture soles (leather, natural or synthetic rubber, PVC, PU). It consists of a laterally moving sample holder and a rotating cylinder to which an abrasive cloth is attached. The abrasive machine must meet the requirements of standard
ISO 4649.
Make /Model /Reference | DW5440 |
Country of origin | China |
Cylinder diameter | 150mm |
Rotation frequency | (40±1)rpm |
Specimen travel speed | (4.20±0.04)mm |
Drum length | 500mm |
Angle of inclination | 3º |
Power supply | AC220V, 50Hz |
Accessories and consumables to be supplied | 1.Main machine 2.Weight (2.5N, 5N) 3.Aluminum 4.Thickness gauge 5.Cutter 6.Brush 7.Collect plate |
Documents to be supplied | - User manual (English) - Detailed spare parts and accessories |
Warranty | 1 year |
More information about textile testing machine and others footware machine .
and contact with us sales@abest-tester.com and visit our website www.abest-tester.com
