Items | Parameters Option |
Control mode | 1.7 inch touch screen +PLC 2.Roll and metering pump frequency control 3. Raw material tank, water bath, coagulation bath, temperature real-time acquisition, display and control 4. Raw material tank pressure real-time acquisition and display 5. Metering pump flow can be displayed in real time |
Raw Material Tank | 1.Volume: 1L, with stirring function 2.With vacuum interface, 6mm nitrogen interface, 3. Having a feeding opening with a glass window 4. Temperature range: RT-80℃ |
Metering pump | 1.Frequency control 2. 0.6cc/rev 3.Temperature control range: RT-80℃
|
Filter | Material: stainless steel
|
Spinneret cap | 1.Material: tantalum 2.External diameter：Ø16mm
|
Coagulation bath | 1.Material: stainless steel 2.Dimensions：1000x160x160 mm 3.Temperature range：0-80℃ 4. With cover
|
Water bath | 1.Material: stainless steel 2. Dimensions:1000x160x160 mm 3.Temperature range：0-80℃
|
Drafting roller | 1.Linear speed: 0- 20m/min 2. Size of roller: Ø50×80mm, 3. Material: stainless steel |
Heating box (drying/setting) | Temperature control range: 0-200℃ adjustable, |
Winding roller | 1.Material: stainless steel 2. Adjustable range of winding linear speed:10-40m/min 3. Tube material：Paper tube
|
