APPLICATION:
Benchtop Wet Spinning Machine Integrated Winders Lab Small Wet Spinning Machine DW7091A
is suitable for preparation of various chemical fiber materials .with adjusting the parameters of air coagulation and coagulation bath, the physical properties of the fiber, such as diameter, strength and elasticity, can be precisely controlled, and various types of fibers can be produced according to different needs.
Features:
1. The spinning machine mainly consists of raw material tank (with heating, stirring), metering pump (heating), filter screen, spinneret cap, coagulation bath (with heating), water bath (with heating), drafting roller, heating box (drying/setting) and winding roller;
2. Touch screen control and display interface;
3. Real-time acquisition and control the temperature of the raw material tank, metering pump, coagulation bath, water bath and heating box;
4. Real-time acquisition and display the raw material tank pressure;
5. Real-time display the flow of metering pump;
6. Roller and metering pump frequency control.
KEY SPEICIFCIAOTN :
Items | Parameters | Remarks |
Control mode | 1 Touch screen + PLC control 2. Real-time acquisition and control of temperature of the raw material tank, metering pump, coagulation bath and stretching bath; 3. Adopt dial pressure gauge to measure the pressure in raw material tank; 4. Real-time display pressure and flow of the metering pump; 5. Adjust the hand wheel to adjust the height of the spinneret assembly; 6.Roller speed is adjustable; |
|
Raw Material Tank*1 | 1.Volume: 1L; 2. Material: stainless steel; 3. Interface configuration: upper feed, inlet and outlet, pressure gauge 4. Electric heating 5. Mechanical seal, speed reduction mixing |
|
Metering system | 1. Metering pump: 0.6cc/rev 2. Electric heating |
|
Filter | 1. Material: stainless steel 2. Filter medium: stainless steel wire mesh |
|
Gooseneck | Material: stainless steel |
|
Spinneret assembly | 1.Material: stainless steel 2. Spinneret cap: 1pc, material: tantalum |
|
Coagulation bath*1 | 1.Material: stainless steel 2. Volume: 20L 3.Electric heating, temperature range: 0-90℃ 4. With transparent organic glass cover and thread guide roller |
|
Drafting bath*2 | 1. Material: stainless steel 2. Volume: 20L 3.Electric heating, temperature range: 0-90℃ 4. With transparent organic glass cover and thread guide roller |
|
Drafting rollers*4 | 1. Linear speed: 1- 20m/min 2. Material: stainless steel |
|
Winding roller | 1. Material: stainless steel 2. Variable frequency reduction speed regulation 3. Adjustable range of winding linear speed: 10-40m/min 4. Tube material: Paper tube φ96*120mm |
|
Metal framework | 40*40 aluminum alloy frame Overall design, segmented connection 304 stainless steel drawing panel |
|
Power supply | 220V/single-phase 50Hz |
|
