Hydrostatic Pressure Testing Equipment for Pipe DW5011B is used to determine the resistance of thermoplastics pipes, composite pipes (PP-R, PP-B, PP-A, PE, PE-X, PVC, PVC-U, PVC-C) under a constant pressure & temperature, or max. pressure value of short time hydraulic burst.
DW5011B
FYI
Silver
1PCS
China
By TT or LC
15-20 days
FEATURES of Hydrostatic Pressure Testing Equipment :
1. Touch screen;
2. All test positions run automatically and are fully independent, each working at a different pressure;
3. Inner and outer surface of the test tank are made of stainless steel;
4. Suitable for small-diameter and also large-diameter specimen;
5. Insulated stainless steel lid with pneumatic operation (Thermostatic water tank);
6. Automatic water level control;
7. The machine stops automatically when the tested pipes or pipe fittings are broken or the test is finished;
8.High accuracy of pressure control;
9. The pressure curves can be saved and the test report can be printed
10. The machine has the feature of auto pressure constant, electronic pressure discharge and cleaning and auto calibration;
11. Double insulation;
12. Integrated overheating protection.
KEY SPECIFICATION of Hydrostatic Pressure Testing Equipment :
Operating pressure | 0.2~10MPa, 0.2-16MPa, 0.2-20MPa (Please advise) |
Display accuracy of the pressure | 0.001Mpa |
Pressure controlling accuracy | -1%~+2% |
Temperature accuracy | ±1°C |
Timing range | 1s~9,999h |
Display accuracy | 1s |
Working position | 3 or please advise |
Power supply | AC380V, 50Hz, 3phase |
STANDARD CONFIGURATION:
No. | Item | Quantity |
1. | Pressure station | 1 set |
2. | Personal Computer | 1 set |
3. | Inlet pipe | 1 set |
4. | High pressure pipe | 1 set |
5. | Stainless steel high pressure pipe | 1 set |
6. | Pipeline for refrigerating machine | 1 set |
7. | Decompression pipe | 1 pc |
8. | Hook | 1 set |
