YLD-3010
FYI
Silver+Black
1pcs
China
APPLICATION:
Benchtop UV Visible Spectrophotometer YLD-3010 is mainly used for color matching analysis and
color quality control.
RELATED STANDARDS:
Note: this Spectrophotometer can conform to but not limit to the standards above,
for more standards conformance,
please contact us.
FEATURES:
1. Perfect combination of beautiful appearance and the human body mechanics structural design;
2. Measure sample spectra, accurate Lab data , can be used in color matching and accurate color transmission;
3.High electronic hardware configuration: 3.5-inch TFT color LCD touch screen, concave grating;
4Use long life and low power consumption combined LED light source;
5. Single 8mm aperture, support both SCI and SCE at the same time;
6.Large capacity storage space, over 20,000 measurement data;
7. Camera Locating Function, better position;
8. PC software has a powerful function extension;
KEY SPECIFICATION:
Optical geometry | Reflect: di: 8°, de:8° (diffused illumination, 8-degree viewing angle) |
Integrating sphere size | 48mm |
Light source | Combined LED light |
Spectrophotometric mode | Concave grating |
Sensor | 256 image element double array cmos image sensor |
Wavelength range | 400-700nm |
Wavelength interval | 10nm |
Semiband width | 10nm |
Measured reflectance range | 0-200% |
Measuring aperture | Single aperture: 8mm/10mm |
Specular component | SCI&SCE |
Color space | CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB |
Color difference formula | ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00v, ΔE(Hunter) |
Other colorimetric index | WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), TI(ASTM E313, CIE/ISO), Metamerism index MI, staining fastness, color fastness, color strength, opacity, 8° glossiness |
Illuminant | A, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, U30, TL83, TL84, U35 |
Displayed data | Spectrogram/values, samples chromaticity values, color difference values/graph, pass/fail result, color offset |
Observer angle | 2°/10° |
Measuring time | 2.6s |
Repeatability | MAV/SCI: ΔE*≤0.05 |
Inter-instrument Error | MAV/SCI: ΔE*≤0.4 |
Measurement mode | Single measurement, average measurement |
Locating method | Camera view finder locating |
Battery | Li-ion battery. 5000 measurements within 8 hours |
Display | 3.5-inch TFT color LCD, Capacitive Touch Screen |
Data port | USB |
Data storage | Standard 1,000 pcs, sample 20,000 pcs |
Dimensions | 184*77*105mm (L*W*H) |
Weight | 600g |
