UV-6000
FYI
White+ Blue
1pcs
China
APPLICATION:
UV-6000 Benchtop Spectrophotometer is used to do precise color analysis and transmission in laboratories
It can be widely applied in different industries, such as plastics, electronics, paint and ink, printing, garments, leather, paper, auto, medical, cosmetics, food, science institutes, laboratories.
RELATED STANDARDS:
Note: this Spectrophotometer can conform to but not limit to the standards above,
for more standards conformance,
please contact us.
FEATURES:
1. Auto identify measuring aperture. Freely switchable between 4 measuring apertures: φ25.4mm/15mm/8mm/4mm. Users also can customize apertures.
2. Built-in temperature sensor to monitor and compensate the measuring temperature to ensure the measurement more precision.
3. High configuration of hardware: 7 inches TFT Color Capacitive Touch-screen Display; Bluetooth 2.1; Concave Grating.
4. Double Array 256 Image Element CMOS Sensor; Long life-span stable LED, UV LED and xenon lamp.
5. With reflective and transmissive spectrum, accurate Lab value, good to calculate color formula and do precise color transmission.
6. Independent light source detector, continuously monitor the condition of light sources to ensure the light source reliable.
7. Multiple measurement modes: Quality Management Mode, Sample Mode; Meet more users’ requirement.
8. Multiple accessories, sample holders, fixation clamp, suitable to more working condition.
9. Big capacity data storage, for 40000 pieces test result.
10. More powerful extended functions at the PC software
11. Wavelength range 360nm – 780nm. Built-in 400nm cut off/420nm cut off/460nm cut off (only xenon lamp edition), more professional in UV measurement.
KEY SPECIFICATION:
Optical geometry | Reflectance: d/8 (SCI⪰ Include UV/Exclude UV) |
Specular Component | Reflectance: SCI&SCE |
Integrating Sphere Size | Φ 154mm |
Sensor | 256 Image Element Double Array CMOS Image Sensor |
Light Source Device | 360nm-780nm Combined LED Lamp, 400nm cut-off, 420nm cut-off, UV Lamp |
Repeatability | Spectral reflectance: Φ25.4mm/SCI, Standard deviation within 0.04% (400 nm to 700 nm: within 0.04%) |
Inter-instrument Error | Φ25.4mm/SCI, Within ΔE*ab 0.15 |
Color | CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB, Munsell, s-RGB, HunterLab, DIN, βxy |
PC Terminal Software | SQCX |
Data Storage Capacity | Standard: 5000 Pcs; Sample: 40000 Pcs. |
Data Port | USB & Bluetooth |
Measurement Mode | Single Measurement & Average Measurement |
Storage Environment | Temperature: -20~50℃; Humidity: 0~85% (No Condensation) |
Working Environment | Temperature: 0~40℃; Humidity: 0~85% (No Condensation) |
Light Source Device Life | 5 years, more than 3 million times measurements. |
Screen | 7" TFT Capacitive Screen-touch Display |
Power Supply | DC 24V, 2A Power Adapter |
Size | 370×300×200mm |
