DW0910S1
FYI
Blue
1PCS
China
By TT or LC
Availability: | |
---|---|
APPLICATION:
Lab Sample Knintter Machine and Lab Knitter Automatic Knitting Machine DW0910S is
used for a combined use with lab dyeing machine to determine the dyeing performance of filament.
FEATURES of automatic knitting machine
DW0910S1, S2, S3
1. Active yarn storage feeder achieves active feeding;
2. Curved needle track and uniform triangle system make sure uniform fabric loop;
3. The number of needles is chosen according to the linear density of yarn. Please refer to the reference
table below.
Linear Density (dtex) | Number of Needles |
| 320 |
22~76 | 300 |
33~111 | 280 |
40~100 | 260 |
111~220 | 220 or 240 |
220~440 | 176 or 200 |
400~660 | 160 |
660~1000 | 120 or 140 |
Over 1000 | 96 |
The Reference Table for Number of Needles
DW0910S2, S3
Cylinder speed and roller speed are settable;
Ergonomic touch panel, digital display and easy operation.
KEY SPECIFICATION:
Model No. | DW0910S1 | DW0910S2 | DW0910S3 |
Applicable chemical fiber | POY | POY, DTY, FDY | |
Rotation speed of cylinder | 10~250rpm, settable | ||
Diameter of cylinder | 3.5 inch | ||
Number of needles | 120~320 (Please inform us the linear density of yarn before placing order) | ||
Touch panel | / | Including | |
Power supply | AC380V, 50Hz, 3phase | AC220V, 50Hz |
