DW1210
FYI
White and black
1PCS
China
By TT or LC
APPLICATION:
Universal Tensile Strength Tester DW1210 is used for mechanical properties test and analyze of non-metallic materials such as tensile, compression and bending.
With three closed-loop control modes of stress, strain and displacement, parameters such as maximum force, tensile strength, bending strength, compressive strength, elastic modulus, fracture elongation, yield strength and so on can be calculated. Test and provide data according to GB, ISO, JIS, ASTM, DIN and other international standards.
Related Standards:
STANDARDS | Tensile | ISO 10319, ISO 10321, ASTM D4595 |
Tearing | ISO 9073.4, ASTM D4533 | |
Puncture | ||
Seam strength | ASTM D4884 | |
Burst | ASTM D3787 |
Note: this tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.
FEATURES:
1.Wide force range to meet various requirements for testing different materials;
2. Precise crosshead guidance via steel columns with carriages seated on ball bearings;
3. Accurate positioning system with servo motor and ball screw lead support;
4. Computer control main machine, easy to operate;
5. Universal software for various material;
6.Real time display data and curve of on-going test by computer;
7. Multiple security protection functions of restrict position controlling, over-load and over-current protection
and automatic stop, safe and reliable.
KEY SPECIFICATION:
Max. testing force | 10KN/20KN/30KN/50KN (Please specify before place order) |
Measuring range of force | 2% ~100% of the full scale |
Measuring accuracy of force | Prior to ±1% of the displayed value |
Speed range | |
Speed accuracy | ±1% |
Max. tensile displacement | 800mm |
Displacement accuracy | ±0.5% |
Effective width of test space | 400mm |
Max. stroke of beam (without clamp) | 1150mm (for max. force ≤30KN) 1000mm (for max. force ≤50KN) |
Power supply | AC220V, 50Hz |
Dimension (L×W×H) | 700×510×1940mm (for max. force ≤30KN) 760×610×2250mm (for max. force ≤50KN) |
Weight | Approx. 290kg (for max. force ≤30KN) Approx. 400kg (for max. force ≤50KN) |
