MU572C
FYI
Silver
1PCS
China
APPLICATION:
Lab Coating Machine MU572Cis a coating machine for lab use, operated by hand with the coating area of 285mm×300 mm, which is used in lab coating technique experiment. It is suitable for laboratorial sampling test including all sorts of natural fiber, synthetic fiber, blended fabric, nonwoven fabric, specialty paper and artificial leather.
FEATURES:
1.High grade stainless steel construction, foundation made of cast iron
2. Import linear sliding track from Germany
3. Equipped ingenious fixture along with blade to block pigment to flow out
4. Gradient of blade can be adjustable from 20° up to 115°
5. Super accuracy of motion up to 0.01mm
6. Stainless steel of structure,
7. Compatible with Mathis LTE-S Labcoater
8. Equipped ingenious fixture along with blade to block pigment to flow out
9. Easy hand operated
10. Easy to remove blade and re-fix it
KEY SPECIFICATION:
Tension Frame | 365mm×440mm |
Coating Area | 285mm×300 mm |
Coating Thickness | 0~5mm |
Accuracy of Coating Thickness | 0.01mm |
Coating Front Angle | 20°~115° |
Blade Type | 45°blade |
Blade Spec | 300mm×60mm |
Roller | Φ40mm×300mm |
Dimensions | 440×680×250mm (L×W×H) |
Net Weight | 30kg |
Optional drying equipment | MU547 Dryer |
STANDARD CONFIGURATION:
No. | Item | Quantity |
1. | Main machine | 1 set |
2. | 45°Blade | 1 set |
3. | Dial gage | 2 sets |
4. | Spanner | 2 sets |
5. | Tension Frame | 1 set |
MORE DETAILED PICTURE OF MU572C TABLETOP LAB COATING MACHINE :
