DW261
FYI
Silver+Black
1pcs
China
APPLICATION:
ISO 17617 Drying Rate Tester DW261 is used for testing the drying rate and time of textiles
after dripping water. For testing, connect the special test software to the precision balance, monitoring
the weight of the test specimen which had been added a certain amount of water, analyze the drying rate
and time of the specimen.
RELATED STANDARD:
STANDARDS | ISO 17617-2014 | GB/T 21655.1-2008, GB/T 38016-2019 |
Note: this Drying Rate Tester can conform to but not limit to the standards above, for more standards conformance,
please contact us.
FEATURES:
1. Special test software can connect up to six balances for simultaneous testing.
2.Data can be transferred from balance to software through USB cable.
3.Testing progress can be observed through software and displayed by curves and tables.
4. The stop conditions can be set through software:
1) According to the test time: The test will stop automatically when it reaches the set time.
2) According to the dry percentage:
Ø The change rate of the mass measured for two consecutive times shall not exceed 1%;
Ø The difference between the quality and the original quality of the specimen before adding water shall not be more than 2%.
3) According to residual water content percentage: the test will stop automatically when the residual water content percentage reaches the set value.
6.Test reports can be saved automatically and printed out.
7. Two kinds of specimen racks can be provided: vertical hanging specimen rack and horizontal specimen rack.
KEY SPECIFICATIONS:
Test software | Can connect up to six balances for simultaneous testing |
Test interface | Display data, curves and tables |
Test stop conditions | According to the test time, dry percentage or residual water content percentage |
Test report | Automatically saved and can be printed out by printer |
Communication interface | USB |
Specimen rack | Vertical hanging or horizontal specimen rack |
