Bursting Strength Tester YG032M is used to determine the bursting strength and distension at burst of a variety of materials, including textiles (knitted and woven), nonwovens, paper, plastics, medical products, etc. It meet with ASTM D3786 etc
YG032M
FYI
White or Black
1PCS
China
YG032M Digital Hydraulic Bursting Strength Tester is used to determine the bursting strength and distension at burst of a variety of materials, including textiles (knitted and woven), nonwovens, paper, plastics, medical products, etc.
ISO 13938.1 ASTM D3786 GB/T 7742.1
Note: Hydraulic Bursting Strength Tester can conform to but not limit to the standards above, for more standards conformance, please contact us.
Touch screen with concise and intuitive interface, simple and convenient to use;
Transparent organic glass cover with built-in LED illumination, easily view tests in progress;
Automatic burst-sensing system, sensitive and reliable;
Four test methods: constant-speed extension until burst, extension to specific pressure, extension to specific distension and extension to specific time;
With data storage and printing functions and support on-line operation.
Hydraulic method;
| Measuring range | 0~2.00MPa or 0~6.00MPa (Please specify before placing order) | ||
| Minimum division | 0.001MPa or 0.003MPa | ||
| Diaphragm thickness | ≤2mm | ||
| Test areas | Standard: 7.3cm²(Φ30.5mm) and 50cm²(Φ79.8mm) | ||
| Optional: 10cm²(Φ35.7mm) and 100cm²(Φ112.8mm) | |||
| Max. distension | 75mm | ||
| Pressurization speed | (20~600)ml/min | ||
| Test methods | 1. Constant-speed extension until burst | ||
| 2. Extension to specific pressure | |||
| 3. Extension to specific distension | |||
| 4. Extension to specific time | |||
| Units | kPa, kg/cm2, bar, lb/in2 | ||
| Output method | Display and print output, support on-line communication | ||
| Power supply of Hydraulic Bursting Strength Tester | AC 220V, 50Hz | ||
| Dimensions of Hydraulic Bursting Strength Tester | 550×450×700mm (L×W×H) | ||
| Weight of Hydraulic Bursting Strength Tester | 125kg |
YG032M Digital Hydraulic Bursting Strength Tester is used to determine the bursting strength and distension at burst of a variety of materials, including textiles (knitted and woven), nonwovens, paper, plastics, medical products, etc.
ISO 13938.1 ASTM D3786 GB/T 7742.1
Note: Hydraulic Bursting Strength Tester can conform to but not limit to the standards above, for more standards conformance, please contact us.
Touch screen with concise and intuitive interface, simple and convenient to use;
Transparent organic glass cover with built-in LED illumination, easily view tests in progress;
Automatic burst-sensing system, sensitive and reliable;
Four test methods: constant-speed extension until burst, extension to specific pressure, extension to specific distension and extension to specific time;
With data storage and printing functions and support on-line operation.
Hydraulic method;
| Measuring range | 0~2.00MPa or 0~6.00MPa (Please specify before placing order) | ||
| Minimum division | 0.001MPa or 0.003MPa | ||
| Diaphragm thickness | ≤2mm | ||
| Test areas | Standard: 7.3cm²(Φ30.5mm) and 50cm²(Φ79.8mm) | ||
| Optional: 10cm²(Φ35.7mm) and 100cm²(Φ112.8mm) | |||
| Max. distension | 75mm | ||
| Pressurization speed | (20~600)ml/min | ||
| Test methods | 1. Constant-speed extension until burst | ||
| 2. Extension to specific pressure | |||
| 3. Extension to specific distension | |||
| 4. Extension to specific time | |||
| Units | kPa, kg/cm2, bar, lb/in2 | ||
| Output method | Display and print output, support on-line communication | ||
| Power supply of Hydraulic Bursting Strength Tester | AC 220V, 50Hz | ||
| Dimensions of Hydraulic Bursting Strength Tester | 550×450×700mm (L×W×H) | ||
| Weight of Hydraulic Bursting Strength Tester | 125kg |
