Y571D
FYI
Silver+Blue
1pcs
China
Availability: | |
---|---|
APPLICATION:
Y571D Crockmeter Rubbing Fastness Tester is designed to determine the color fastness of textiles
] to dry or wet rubbing, and provided with a crocking finger with a downward force of 9 Newton
and the facility for mounting standard crocking fabric. A pinned acrylic sample holder ensures rapid sample mounting and repeatability of results. It is electronically driven to minimize operator variation..
RELATED STANDARDS:
STANDARDS | ISO 105 X12, ISO 105 D02 | AATCC 8, AATCC 165 |
Note: this Crockmeter Rubbing Fastness Tester can conform to but not limit to the standards above, for more standards conformance, please contact us.
FEATURES OF CROCKMETER :
1. Presetting the rubbing times, and the instrument stop when reach the presetting times;
2. Simple operation;
3. Purpose-designed test mode;
4. Automatic flame application.
KEY SPECIFICATION :
Loading pressure of brush and size | 9±0.2N |
Circular: Φ16mm | |
Square: 19×25.4mm | |
Motion Range of crocking finger | 104±3mm |
Shuttle times | 1-9,999 |
Rotational Speed of Winch | 60rpm |
Crocking finger | Standard brush |
Max Dimension of Specimen | 220×110×5mm |
Power Supply | AC220V, 50Hz, 40W |
Dimensions | 770×280×250mm(L×W×H) |
Net weight | 15Kg |
